How to Handle Secrets on the Command Line

Carl Tashian

Follow Smallstep

The command line really wasn't designed for secrets. So, keeping secrets secret on the command line requires some extra care and effort. The other day in my homelab I was configuring a TLS client certificate for a Grafana datasource. The intention was to write something I could run on a timer whenever the certificate is renewed. The command needed to:

1. Build some JSON with the renewed certificate and private key injected into it
2. PUT it to Grafana's API to update the datasource configuration.

I thought I was being very clever when I wrote this lil' Bash pipeline:

BEARER_TOKEN=MhY3b3i3gFpa9otnLQVznJYoWLxpGJUod3iDJwCKRFUVtuALGJooBJuCUf7w9HJfbu;
jq -n
     --arg ca_cert "$(< $STEPPATH/certs/root_ca.crt)"
     --arg client_cert "$(< $CERT_LOCATION)"
     --arg client_key  "$(< $KEY_LOCATION)"
      -f ./datasource.jq
 | curl -s -X PUT
      -H "Content-Type: application/json"
      -H "Authorization: Bearer $BEARER_TOKEN"
      -d "$(< /dev/stdin)"
      --cacert $STEPPATH/certs/root_ca.crt
      https://grafana:3000/api/datasources/2

This uses jq to populate a JSON template for an API request (datasource.jq) with variables passed in with --arg, and then PUTs to the API with curl. Nice, huh?

It didn't take long to discover that this pipeline leaks secrets all over the place:

• The private key credential file is leaked: "$(< $KEY_LOCATION)"
• The bearer token env variable is leaked: -H "Authorization: Bearer $BEARER_TOKEN"
• And the secret piped data from STDIN is leaked: -d "$(< /dev/stdin)"

All of these values, including the precious contents of the private key file, can be seen via ps when these commands are running. ps finds them via /proc/<pid>/cmdline, which is globally readable for any process ID.

To make atonement, I'm writing this post. We'll look at three methods for handling secrets on the command line: Using piped data, credential files, and environment variables. We'll look at some of the risks of these approaches, and how to use each of them as safely as possible.

But first, let's look at a sanitized version of the above pipeline:

jq -n
   --rawfile ca_cert $STEPPATH/certs/root_ca.crt
   --rawfile client_cert $CERT_LOCATION
   --rawfile client_key $KEY_LOCATION
   -f ./datasource.jq
| curl -s -X PUT
   -H @api_headers
   -d @-
   --cacert $STEPPATH/certs/root_ca.crt
   https://grafana:3000/api/datasources/2

Notably:

• The --rawfile flag in jq moves the credentials closer to where they are used by delegating the responsibility for reading the certificate data from the files to jq instead of bash.
• Once jq pushes the secret JSON into the pipe, curl uses the -d @- flag to pull the secret data directly from the pipe and use it as the HTTPS request body.
• And -H @api_headers will read the static bearer token from a file (api_headers).

Now, no secrets will appear in ps—only filenames.

Piped Secrets

As the sanitized example shows, a pipeline is generally an excellent way to pass secrets around, if the program you're using will accept a secret via STDIN. Because a pipe only has two ends, right? Imagine yourself whispering a secret into one end of a pipe, and a friend putting their ear up to the other. It's just like that.

Usually. The $(< /dev/stdin) leak shown above uses a neat Bash substitution to make an otherwise secure pipe insecure. For example, if you run:

$ echo "secret-data" | curl -d "$(</dev/stdin)" https://example.com:3000

Then the output of ps for curl will show:

curl -d secret-data https://example.com:3000

Other than that, there's not too much to worry about with pipes.

Credentials Files

What's not to love about a file? It's got an owner. It has permissions and access control. Give each secret a file! Any program that accepts secrets should be able to accept them by passing a filename or by redirecting a file into STDIN. You can also use files to pass secrets into Docker containers with mounted volumes.

A few notes about storing and retrieving file secrets:

• You'd better get the permissions right
• Avoid leaking the secret in the command string eg. with "$(< secret_file.txt)"
• Be sure your disk is encrypted at rest, eg. with LUKS
• You may want to encrypt the contents of the file — but, then you need to figure out how to handle the encryption key.

Environment Variables

Using environment variables for secrets is very convenient. And we don't recommend it because it's so easy to leak things:

• Some operating systems still make every process's environment variables world readable. (But, in all the Linuxes I've seen, /proc/<pid>/environ is not world-readable.)
• In Docker, anyone with access to the Docker daemon can use docker inspect to see all of the environment variables for any running container.
• In systemd, environment variables in unit files are available to users via the dbus interface (see the recent introduction of LoadCredential= for an alternative that uses credential files)
• Exported environment variables will get passed to every new process, and then who knows what will happen to them. They might get dumped to STDOUT or logged to a debug logfile.
• Local (unexported) shell variables are also easy to leak into ps output:

  $ BEARER_TOKEN=MhY3b3i3gFpa9otnLQVznJYoWLxpGJUod3iDJwCKRFUVtuALGJooBJuCUf7w9HJfbu;
  curl -s -X PUT
      -H "Content-Type: application/json"
      -H "Authorization: Bearer $BEARER_TOKEN"
  ...


• Variables can easily end up in shell history. In many shells, adding an extra space before a command will exclude it from shell history.
  • In Bash, the HISTCONTROL variable must be set to ignorespace.
  • In the Fish shell, run fish --private to start a private mode Fish session.
• Secrets can also slip into your editor's search history. For example, in vim there's a $HOME/.viminfo file that contains search history. Run vim -i NONE to disable it for a session.

If a command takes a password filename, you can use a password environment variable if you're careful about it. For example, say we have a $STEP_CA_PASSWORD environment variable, and we run the following in Bash:

$  STEP_CA_PASSWORD=amazingpw; step-ca --password-file <(echo -n "$STEP_CA_PASSWORD") $(step path)/config/ca.json

The /proc/<pid>/cmdline for this process will contain something like:

step-ca --password-file /dev/fd/11 /home/carl/.step/config/ca.json

Using this <() syntax of process substitution, Bash will create a file using the output of echo -n "$STEP_CA_PASSWORD" and supply that file's name to --password-file.

Great, right? Except...wouldn't the /proc/<pid>/cmdline for the inner echo contain:

echo -n my-secret-ca-password

Thankfully, in Bash, the answer is no. We are saved by the fact that echo is a builtin, and a process will never be created. So, if you are able to otherwise secure your environment variables, this approach is safe. The downside is that it appears unsafe, because $STEP_CA_PASSWORD is still getting substituted into something that certainly looks like it's a command.

What About A Secrets Manager?

Secrets managers can be great because they can make it easier to get secrets closer to where they are used. For example, a Docker container can call out to a secrets manager for its secrets. But, a secrets manager is an extra dependency. Often you need to run a secrets manager server and hit an API. And even with a secrets manager, you may still need Bash to shuttle the secret into your target application. For this post I'm focused on more lightweight solutions.

Speaking of lightweight solutions, there is an keyring facility in the Linux kernel. The Linux keyring offers several scopes for storing keys safely in memory that will never be swapped to disk. A process or even a single thread can have its own keyring, or you can have a keyring that is inherited across all processes in a user's session. To manage the keyrings and keys, use the keyctl command or keyctl system calls.

Directly in the command

In case it isn't already abundantly clear, this is very unsafe. There is no way for the caller of a command to choose to hide the command line from being world readable. So, any CLI command worth its salt should not accept passwords directly.

You could maybe pass a password directly in a command if you were running inside a secure container with sandboxing around everything. But, why take the risk?

Now, even for this one there's a caveat. Have you ever run mysql this way?

$ mysql --user carl --password amazingpw db.smallstep.com

Or curl this way?

$ curl -u carl:password https://example.com:3000

These commands accept passwords against their own better judgement, for convenience. But, immediately upon startup, they will overwrite argv with a blank value, effectively hiding the secret. If you run ps during the curl command shown here, you'll see:

curl -u               https://example.com:3000

Now technically, if a system is overloaded enough, it could be possible to grab the secret from /proc/<pid>/cmdline before curl has a chance to overwrite it. But, this approach is better than nothing at all. And these passwords can easily end up in audit logs or shell history. So, better to avoid this approach entirely.

The alternative for curl is a credential file: A .netrc file can be used to store credentials for servers you need to connect to.

And for mysql, you can create option files: a .my.cnf or an obfuscated .mylogin.cnf will be read on startup and can contain your passwords.
